Decentralised
VLR 70 S Trend EN

  • 360°
    • Decentralised ventilation unit for rooms with external walls
    • Very easy to clean thanks to the aluminium surface of the heat exchanger
    • Can provide intensive ventilation with low noise emissions
    • High air quality, plus long service life through the use of two filters per fan
    • Fitted with a fine dust/pollen filter making it ideal for allergy sufferers
    • Moisture recovery of up to 60 %
    • Control up to 8 units with the user interface
    • Recovery of up to 92 % of the thermal energy in the extract air
    Questions about the product Get contact

    Product details

    Experience a strong performance in an inconspicuous design

    This decentralised ventilation unit supplies fresh air to up to 60 m² of living space. Virtually no heat is lost, as it is fed back into the room with the outdoor air supply. This can help to reduce heating energy losses by as much as 89 %.

    Keep pollutants out

    Dirt and pollen don't stand a chance of finding their way into your home through this ventilation unit. Particularly good filter performance is achieved by filters on both the inside and outside of the unit. As a result, people with allergies can breathe a sigh of relief as well.


    Reach-Information
    Technical datasheet

    Product Number: 200002

    Type of ventilation: decentralised supply and extract air

    Power consumption: 2-12 W

    Rated voltage: 24 V

    Sound power level LW total relative to air flow rate: 35 (20 m³/h) dB(A)

    Weight: 5.20 kg

    Min. outlet aperture: Ø 200, 185x185 mm

    Height: 285 mm

    Width: 360 mm

    Depth: 590 mm

    Air flow rate: 20/30/40/49/70 m³/h

    Heat recovery level up to: 92 %

    Show all

    Download as PDF

    Equipment datasheet

Installation Information:

Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
